Engineered for fast on-site conveyor belt repair in mining, ports, coal handling, and bulk material operations.
Fast Curing
High Bond Strength
Wear Resistant
Flame Resistant
Anti-Static
Minor belt damage can rapidly develop into unplanned shutdowns, material spillage, and costly maintenance interruptions.
Traditional repair methods often require extended curing time, delaying production recovery and increasing operational risk.
Edge Tear
Abrasion
Impact Damage
Cover Gouging
BOTON Rapid Repair Compounds are engineered for fast, durable conveyor belt repair directly on site.
With rapid curing chemistry and high wear resistance, damaged belts can quickly return to operation without lengthy shutdown procedures.
Available in flame-resistant and general-purpose versions for different operating environments.
Prepare
Apply
Back to Service
Operational strength achieved in as little as 30 minutes.
Up to 9 N/mm adhesion strength for durable repair performance.
Designed for high-abrasion bulk material environments.
Suitable for underground coal and flame-resistant conveyor systems.
Designed for underground mining and flame-resistant conveyor systems.
Designed for standard conveyor belt repair under general operating conditions.
Belt Edge Damage
Cover Abrasion
Impact Gouges
Splice Wear
Surface Cracks
Exposed Reinforcement
Northern China Underground Coal Mine
A flame-resistant aramid conveyor belt experienced severe edge damage underground, including a longitudinal cut approximately 10 meters in length and up to 5 mm in depth.
The repair had to be completed directly on site under underground mine conditions at approximately 22°C, while minimizing production downtime.
BOTON S01 Flame Resistant Repair Compound was applied for rapid on-site recovery of the damaged belt edge area.
The repair was completed using:
Large Underground Mining Operation, Inner Mongolia, China
Multiple underground conveyor systems showed localized splice wear and surface abrasion under continuous mining operation.
The affected belts included:
- Flame-resistant aramid belts
- Steel cord conveyor belts
Wear depth at splice areas reached approximately 2–3 mm, with additional localized surface damage observed across several belt sections.
Underground ambient temperature during repair was approximately 15°C.
BBOTON S01 Flame Resistant Repair Compound was used for rapid repair of:
The project utilized:
| Property | S01 | G01 |
|---|---|---|
| Initial Cure | 30 min | 30 min |
| Tensile Strength | ≥8 MPa | ≥16 MPa |
| Elongation | ≥450% | ≥350% |
| Abrasion Loss | ≤120 mm³ | ≤90 mm³ |
| Bond Strength | ≥3 N/mm | ≥2 N/mm |
| Flame Resistance | Yes | - |
Talk to BOTON about fast conveyor belt repair solutions for your operation.
